10 02-2023 6095 00
INSTANT PRODUCTS AND SUGAR
It is advisable to use quality instant prod-
ucts to avoid any malfunction of the equip-
ment due to the presence of impurities.
1. open the instant powder canister cover.
2. fill with instant powder
3. close the cover carefully.
-
ing.
have loaded are not lumpy.
MAX
Fig. 6
REFERENCE CUP
SPECIFICATIONS
Fig. 7
CUPS
The cup dispenser shelf has got a double
articulated joint intended to improve the
accessibility to the cup dispenser for lling
columns.
To load the columns, act as follows:
-Open the machine door
-Pull the shelf to release the dispensing
compartment
-Turn the shelf to the outside
-Remove the cover from the cup stacker;
-Load the cups
Fig. 8
1. Cover
2. Cup column
Capacity 12 oz
Height 114.50 mm
Diameter 81.20 mm
Weight 8.50 g
Type Vending
Line Single Wall
Material PE Coated Paper
