EVS Multicam Version 10.01 – Operating Manual
EVS Broadcast Equipment SA – July 2009
Issue
10.01.F
91
11.4.2.2 VIA THE VGA CLIP SCREEN
To activate a playlist via the VGA clip screen, proceed as follows:
1. From the clip screen, press END to access the playlist bank.
2. Press the DOWN arrows until you select the playlist to activate.
3. Pressing ENTER on the selected playlist activates it.
11.4.3 HOW TO RECALL AND LOAD A PLAYLIST
You can only recall and load a playlist if this is not empty.
To load a playlist on a player channel, proceed as follows:
1. Access the desired playlist bank by pressing F10 from the requested
page.
2. Select the playlist to load with the F1-F10 keys.
The selected playlist becomes active and is displayed on the LCD
display.
3. Press PLST key on the Remote Panel to load the active playlist.
If the new playlist is not empty, it is automatically loaded on the selected
player channel (in 3 PGM mode) or on the PGM (in PGM/PRV mode) and it
becomes the current playlist.
If the new playlist is empty, the system will ask you whether you want to
copy the current playlist at this new location.
11.4.4 HOW TO EXIT THE PLAYLIST MODE
Press the RECORD key on the Remote Panel to exit the playlist mode and
return to E2E mode.
