EVS Multicam LSM Operating Manual

EVS Multicam Version 10.01 – Operating Manual
EVS Broadcast Equipment SA – July 2009
Issue
10.01.F
125
• IN point and OUT point, for the section to replace in the playlist. The
OUT point can also be defined during the Replace itself.
• Loop mode parameters. See also the section ‘Loop Mode in the Replace
Fu
nction’, on page 127.
In t
he Replace Edit mode, the playlist is considered as one entity on which
you can mark one IN point and one OUT point (pressing the IN and OUT
points does not retrim the current playlist clip).
Those IN and OUT points will be used to determine what portion of the
playlist will be replaced.
11.14.3.2 THE REPLACE PLAYBACK MODE
In this mode, you play the playlist back and insert the new section between
the defined IN and OUT points.
After you have selected the required settings for the Replace function, the
Replace Playback mode is automatically activated: the playlist is cued
before the IN point (to create guardbands), ready to be initiated.
The playlist is played at the speed defined in the playlist but the lever can
also be used to vary the playback speed.
When the Protect OUT point of the clip is reached, a clip containing the IN
and OUT point with the guardbands is created on the Receive page defined
in the Setup menu. The loop is stopped and the user switches back to match
frame edit mode.
11.14.4 REPLACE WITH IN/OUT POINTS OR WITH IN POINT
ONLY
You can perform a Replace action in two ways:
• by defining an IN and OUT points in the Replace Edit mode.
• by defining only an IN point in the Replace Edit mode, and defining the
OUT point while you perform the Replace in the Replace Playback mode.
For more information on how to perform a Replace, refer to the section ‘How
t
o Perform a Replace’, on page 125.
Impo
rtant
The IN and OUT points can not be marked on a transition
(including split audio transitions and swap zones) or on a split
zone (the key will flash red when it is the case).
11.14.5 HOW TO PERFORM A REPLACE
You first define the Replace function in the Replace Edit mode. Then, you
execute the Replace function in the Replace Playback mode.
To perform a Replace, proceed as follows:
1. Open the playlist in which you want to replace a section in Playlist
Edit mode.
