4.2 SELECTION OF CLIP BANKS AND
PLAYLISTS
SHIFT + F1 - F9 = CLIPS BANK
This allows access to clip banks 1 through 9 within the clip page (1 to 10).
SHIFT + F1 = BANK 1
SHIFT + F2 = BANK 2, etc. (up to bank 9)
Once in the bank, selection of the F1 – F10 keys will call up the respective
clips. If Recall Clip Toggle is enabled in the Setup menu, pressing several
times on the same F_ key will call successively all camera angles of that
clip.
The clip numbering system is as follows:
Example: Clip 547 where
• “5” refers to the clip page number (1 to 10).
• “4” refers to the clip bank (1 to 9)
• “7” refers to the clip number (1 to 10) inside the bank
Note
To identify remote clips when using the XNet SDTI network, the
number of the clip is followed by the number of the machine on the
network. i.e. Clip 547B/04
SHIFT + F10 = playlist BANK
This combination of keys gives access to the playlists’ banks. Within each
clip page there are 10 playlists. Selecting F1-F10 at this point calls up the
corresponding playlist.
Example: Playlist 51 where
• “5” refers to the clip page
• “1” refers to the playlist number (1 to 10)
Note
• The playlist bank of page 10 is not available from the EVS
remote, since it is actually reserved for the EVS AVSP protocol
(for Air Box and Air Edit).
• To identify remote playlists when using the XNet SDTI network,
the number of the playlist is followed by the number of the
machine on the network, i.e. Playlist 51/04
