11.13.4 HOW TO PERFORM A SWAP AUDIO TRACK IN
MANUAL MODE
If the manual mode is selected in the Setup menu (page 4.2, F3), the swap
functions in a similar way but asks the operator which track to swap when
setting the swap points.
STEP 1
First the operator is being asked to select the original track:
• In 2 Tracks mode: you select between the tracks 1,2 or Menu to Cancel.
• In 4 Tracks mode: you select among the tracks 1 to 4, or Menu to
Cancel.
• In 8 Tracks mode: you select among the tracks 1 to 8, or Menu to
Cancel.
• In 16 Tracks mode: you select among the tracks 1 to 16, or Menu to
Cancel. The tracks 1-8 are displayed on a 1
st
page and the tracks 9-16
are available via F10 on a 2
nd
page.
The functions keys are used to select the track to change.
STEP 2
When the choice is made, the operator selects by which track the selected
one has to be replaced:
• In 2 Tracks mode: you select the new track between 1, 2 or 0.
• In 4 Tracks mode: you select the new track among 1 to 4, or 0
• In 8 Tracks mode: you select the new track among 1 to 8, or 0
• In 16 Tracks mode: you select the new track among 1 to 16, or 0. The
tracks 1-8 are displayed on a 1
st
page and the tracks 9-16 are available
via F10 on a 2
nd
page.
Several swap points can be set on the same timecode (e.g.: 1 -> 3, 2 -> 4).
Note
Selecting track 0 will mute the output until the next swap point or
the end of the clip.
11.13.5 DELETING SWAP POINTS
When the operator is on a swap point, pressing CLEAR + IN/OUT deletes the
current swap point. All swap points for that time code are deleted.
