18.2 OVERVIEW ON COMMANDS
18.2.1 MAIN MENU
The Hypermotion menu includes the following main and a secondary menu.
The main menu displays the blocks that have been selected in the #Blocks
parameter of the secondary menu. Only the activated blocks will be
displayed. The block highlighted is the one the operator is currently working
on.
18.2.2 SECONDARY MENU
Pressing the MENU key opens the secondary menu:
# Blocks Pre-Roll PGMSpeed 2ndLever
2 00s10fr 50% +- 1000
The secondary menu gives access to the hypermotion settings described in
the table below. To modify a setting, press the corresponding softkey and
jog to select the requested value.
Setting Description Values
#Blocks Number of memory blocks of the
hypermotion camera to be used.
The number of blocks displayed in the
main menu depends on the number of
blocks specified in this parameter.
1 to 4
(default: 1)
Pre-Roll Pre-roll for the cue points defined on the
material recorded on the hypermotion
camera.
The last cue command will go to the
desired TC - pre-roll if the material is
available. If not, the pre-roll is not
applied.
From 0s01fr to
05s00fr
(default: 00s00fr)
PGMSpeed PGM speed that is to be applied for
playing back material recorded on the
hypermotion camera.
50, 100 (default),
200, 300, 400,
1000
Hyper Motion Camera Mode
# Blocks Pre-Roll PGMSpeed 2ndLever
2 00s10fr 50% +- 1000
LSM Mode
Block 1 Block 2
