EVS Multicam Version 10.01 – Operating Manual
EVS Broadcast Equipment SA – July 2009
Issue
10.01.F
151
15. Target Mode
15.1 INTRODUCTION
Note
The Target Mode is a software option, which requires the licence
code 114 being installed. For more information on the required
licence key, contact the Support or Sales team.
This software option enables the tracking of an object/action by use of a
circle, arrow, ellipse or rectangle
1
, focusing the attention on certain details.
The user can choose the size, colour and thickness of the border as well as
the darkness of the background for a highlight feature. The addition of the
Loop function allows the operator to store this effect as a clip.
The facilities within this software package can be operated using the tablet
and the stylus, or a touch screen. Selected in the Setup menu, the normal
pointing device is the tablet, selecting F2 in page 6.2 will toggle between
tablet / touch screen (only when the touch screen is available). The touch
screen must always be connected to the RS422 port #6 and defined on page
7.2 (F6) of the Setup menu.
1
In this chapter, we use the words “tracking object” to refer to the type of shape
selected by the operator (circle, arrow, ellipse or rectangle).
