EVS Multicam Version 10.01 – Operating Manual
EVS Broadcast Equipment SA – July 2009
Issue
10.01.F
31
7.1.2 OPERATIONAL MENU
The operational menu in Multi PGM mode gives access to the functions
detailed in the following paragraphs:
RST CAM
This function restores the position of cameras on the active channels: CAM
A on PGM1, CAM B on PGM2, etc.
Note
When a clip/playlist is loaded on a channel, switching back to Live
mode will recall the record train, which was last used on that
output. This avoids too frequent uses of the Rst Cam function.
SYNC TO
This button allows you to synchronize the selected PGM in use with another
one. Press this button and then select the PGM to be used as a reference.
This function is not available with network trains.
TOGGLE / ALL
The Toggle function is only available in 3PGM mode:
• Toggle OFF: Selecting an output channel results in controlling that
channel and disables the control on others.
• Toggle ON: Selecting a channel will alternatively enable/disable the
control over that channel without changing the control on the others.
• All: This enables the control on all channels.
2ND CTRL
This function allows the operator to swap the control of one or several play
channels between the EVS remote and a third-party controller using the
Sony BVW75 or XtenDD35 protocol. Both controllers receive permanently the
status of the channel(s), but only one controller at a time is able to actually
control a channel. The secondary controllers are defined in Section 7 of the
remote Setup Menu.
