EVS Multicam Version 10.01 – Operating Manual
EVS Broadcast Equipment SA – July 2009
Issue
10.01.F
95
11.5.6 INSERTING “RECORD IN PROGRESS” CLIPS INTO
PLAYLISTS
“Record in progress” clips can be inserted in playlists in the same way as
other clips. However, their display has the following characteristics:.
Display
They will be displayed with the ‘Creating’ message in the playlist on the
VGA.
The “Record in progress” clips ID will be blinking on the mini playlist display
and on the playlist screen on the Remote Panel, as well as on the OSD.
Remaining Time
The remaining time in playlists containing “Record in progress” clips with
only an IN point is as follows:
The remaining time displays --:--:-- on all the screens (OSD, VGA, Remote
Panel screen) where this information is displayed.
11.6 NAMING A PLAYLIST OR AN
ELEMENT IN A PLAYLIST
You can name a playlist from the VGA Playlist Bank screen or from the VGA
Playlist screen.
11.6.1 HOW TO NAME A PLAYLIST FROM THE VGA
PLAYLIST BANK SCREEN
To name a playlist from the VGA Playlist Bank screen, proceed as follows:
1. From the Clip screen, press END to go to the Playlist Bank screen of the
requested page.
2. Press the down arrow several times until the playlist to name is
selected.
3. Type the desired name on the keyboard.
It appears in the Name field at the bottom of the screen. Use
<BACKSPACE> to delete the last character, or ESC to clear the entire
field.
4. Press F1 to assign the new name to the current playlist.
The playlist name will appear in the title bar next to the playlist number.
