EVS Multicam Version 10.01 – Operating Manual
EVS Broadcast Equipment SA – July 2009
Issue
10.01.F
139
13. Operating on XNet Network
13.1 INTRODUCTION
The XNet Network is set up in the EVS application. For more information, on
how to set up the XNet Network and connect to the XNet network, refer to
the section XNet SDTI Network in the Multicam Configuration manual and to
the XT Tech Ref Software manual.
13.2 DISCONNECTING FROM XNET
When you work on the XNet Network and exit Multicam, the system checks if
other systems are still connected to your server.
In this case, the following message appears:
Other users are connected to your LSM
on XNet network. Are you really sure that
you want to close the Multicam application ?
[ESC] =CANCEL [ENTER]=YES
Press ESC to cancel the command and return to the application.
Press ENTER to exit the Multicam application.
13.3 SELECTING A SERVER ON XNET
Selecting the NETWORK key (SHIFT + PLAY on the Remote) displays the
Network menu:
The LCD screen of the Remote displays the complete list of available
systems on the network. The list is organized by the order of connection to
the network. Up to 4 pages are available to display up to 31 servers.
Select a LSM on XNET Page 1/4
F1 MICHEL F6 MACHINE6
F2 PIERRE F7 MACHINE7
F3 PAUL F8 MACHINE8
F4 JACQUES F9 MACHINE9
F5 ANDRE (LOCAL) F0 MACHINE0
Previous Next
Local Clips Records Clip+Rec
To Next Page
