EVS Multicam Version 10.01 – Operating Manual
EVS Broadcast Equipment SA – July 2009
Issue
10.01.F
159
16.2 HOW TO MARK AN OFFSIDE LINE
To mark an offside line on a clip or record train, proceed as follows:
1. Load the clip or train on the PGM1 and jog to the position where the
offside line should be marked.
2. Press SHIFT-D to access the offside line menu:
TRANSP OSD QUIT
SHIFT SIDE REDO UNDO
The SHIFT function is active by default.
3. Jog to position the line horizontally with the SHIFT function.
4. Press the A key to toggle from the Shift to the TILT function.
5. Jog to tilt the line to the requested angle with the TILT function.
If desired, you can move the position of the pivot point used to set the
inclination of the line.
6. From step 3 to step 5, you can redefine the frame at any time by
pressing PRV CTL and jogging to the requested frame. Click again
PRV CTL to continue to edit the offside sequence.
7. Once the 1
st
line is set, press TAKE to fix it.
8. If desired, you can then jog to move the pivot point and press TAKE a
second time. Then you can jog to break the line and change its
inclination from the pivot point.
You can repeat this step several times to precisely delimit an offside
zone on the pitch.
9. At any time, you can do one of the following:
• Press the B key (Side) to change the side of the shaded area for
the offside zone along the offside line. By default, this is defined
on the left of the offside line.
• Press the SHIFT+B key (Trans.) to change the transparency of the
offside zone with the lever or the jog.
10. Press Mark to validate the line position.
The offside line is maked and can be replayed as long as you are in the
offside mode.
If you want to define another offside sequence, you need to quit the offside
mode and come back to it.
