EVS Multicam Version 10.01 – Operating Manual
EVS Broadcast Equipment SA – July 2009
Issue
10.01.F
21
5. Control Mode
Multicam can be set in three different basic modes, depending on commands
used.
5.1 LIVE (E2E) MODE
This mode selected at start-up can also be selected by pushing the RECORD
key. Multicam records the input signal and plays it at the same time on the
program output.
5.2 SEARCH MODE
This mode is selected by moving the jog dial.
In this mode, the operator has the opportunity to search for an image, in
order to define cue points or clips. Moving the command knob clockwise will
force Multicam to search forward, moving the command knob counter
clockwise will force it to search backwards. The most important thing to note
is that Multicam never stops recording while searching.
5.3 PLAYBACK MODE
Moving the lever or pressing the PLAY key selects this last mode.
Multicam plays the incoming signal delayed, a clip or a playlist, in slow
motion, and of course, continues to record the incoming signal on disks.
As soon as the lever is moved, Multicam starts playing back from the current
picture. The playback speed is defined by the lever position. This is used to
start the playback of a normal slow motion, as well as the playback of a clip
or a playlist. During playback, the system never stops recording
Each operation on the Remote Panel with the command KNOB or LEVER will
be associated to the Search or Playback mode respectively.
