EVS Multicam Version 10.01 – Operating Manual
EVS Broadcast Equipment SA – July 2009
Issue
10.01.F
37
• The guardband beyond the Short OUT point is created with the
material available when the operator saves the clip by pressing
the selected F_ key. Therefore, this guardband can sometimes
be shorter than the value defined in the Setup menu.
9.1.2 CLIP AVAILABILITY ON DISKS
Various clip types can be distinguished depending on whether they are
available on the disks or not. Depending on the clip availability on disks,
you can perform specific actions on the given clip or not.
Clip on disk Clips which are protected on disks, and which have
Short IN and Short OUT points present on disks.
All the material is available on the disk.
“Record in
progress” clip
Clips which are protected on disks, and which have an
Short IN and Short OUT points defined on disks.
Since the record process is still undergoing, some of
the material is already on the disk but not all of it.
Reserved clip Clips for which the position has been reserved on the
SDTI database but for which there is no Short IN and
Short OUT points, nor any protect present on disks.
9.2 USING THE EVS REMOTE PANEL
9.2.1 HOW TO CREATE A CLIP
To define a clip, proceed as follows:
1. Select the LIVE mode.
2. Using the jog dial, define your Short IN point. Press the IN key to
mark your Short IN point of the clip.
3. Search for the desired Short OUT point and then press the OUT key to
mark it.
A clip can be created with only IN point or only OUT point. The system will
automatically define the clip duration according to the default duration
defined in the Setup menu.
Note
You can mark an IN or OUT point on a paused record train and go
back to live without losing the point marked by pressing SHIFT-
<Return>.
