Issue
10.01.F
EVS Multicam Version 10.01 – Operating Manual
EVS Broadcast Equipment SA – July 2009
152
15.2 CREATING A TARGET TRACK
Begin by selecting all the appropriate types of tracking object, their size,
colour, etc.
15.2.1 SELECTING THE TYPE OF TRACKING OBJECT
The character on the left of the “T” letter on the 1
st
line of the OSD shows
the current object:
O (letter “o”) Indicates a circle (default option)
0 (zero) Indicates a ellipse
↓ / ↑ / → / ← Indicates an arrow
█ Indicates a rectangle
Z Indicates the zoom mode is active (circle only
available in this mode)
15.2.2 SELECTING OTHER PARAMETERS OF THE TRACKING
OBJECT
T: Select the background shade (Transparency level)
E: Select the border thickness (Edge)
S: Select the size of the tracking object (Size)
C: Select the border colour (Colour)
Note
To select the size of the tracking object when it is a rectangle
or an ellipse, click on S on the first line of the OSD. You must
define the position of 2 opposite corners of the rectangle (in case
of an ellipse, you must define the opposite corners of the
rectangle the ellipse in enclosed in). When these 2 corners are
defined, the system draws the resulting rectangle or ellipse. You
can confirm by clicking on OK or clear the screen by clicking on
CLEAR and redefine a new shape.
