EVS Multicam LSM Operating Manual

EVS Multicam Version 10.01 – Operating Manual
EVS Broadcast Equipment SA – July 2009
Issue
10.01.F
107
11.10.7.2 PROCESS
To regenerate the timecode in a given playlist, you will perform the following
actions:
1. Activate the TC Regeneration and define the related settings on the
Playlist page (F10), in the blue-highlighted area at the bottom of the
page. This feature is defined for each playlist individually:
2. Activate the internal loop using the SHIFT+LOOP keys
3. Roll the playlist.
This will record the playlist back into the recorder channel 1 (CAM A)
with the regenerated timecode.
11.10.7.3 ACTIVATING THE CONTINUOUS TIMECODE REGENERATION
To activate the continuous timecode regeneration, proceed as follows:
1. In the Playlist page (F10), press <TAB> several times until the
ON/OFF field after ‘Regeneraltion of TC’ is green highlighted.
2. Press the right arrow key to toggle the function to ‘ON’.
The continuous timecode regeneration function is now active. However, the
timecode will effectively be regenerated when you replay the playlist after
activating a loop.
To deactivate the function, press the left arrow on the field to toggle the
function to ‘OFF’.
11.10.7.4 SETTINGS FOR CONTINUOUS TIMECODE IN PLAYLISTS
The following table describes the various parameters that should be defined
when regenerating the timecode in a playlist:
Parameter Description Possible Values
Continuous in … Specifies whether the timecode
should be continuous for the whole
playlist or for each playlist
element.
PLST, CLIP
From … Specifies the initial TC value to be
used for the timecode
regeneration
Timecode, LTC TC,
User TC
In … Specifies the TC type in which the
timecode should be regenerated
LTC or VITC in SD
HANC VITC, HANC
LTC or both
