Issue
10.01.F
EVS Multicam Version 10.01 – Operating Manual
EVS Broadcast Equipment SA – July 2009
6
1. F-keys & small
buttons
Multi-purpose keys
2. Soft keys With LCD display, allows the operator to enter the
Multicam MENU system
3. Lever Initiates slow motion and playlist replay
4. Jog dial Used to accurately cue disk recorder
5. Operational
block 1
PLST Initiates active playlist
LOOP This option records the main output (PGM1) to the
first input (CAM A) of Multicam.
BROWSE Used to browse through clips, playlists, cue points
INSERT Used in playlist management to insert clips into a
playlist
IN Sets Mark IN at the current position
GOTO IN Goes to the defined Mark IN
OUT Sets Mark OUT at the current position
GOTO OUT Goes to the defined Mark OUT
TAKE In PGM+PRV mode, pressing this button swaps
cameras on PGM and PRV monitors
In Multi-PGM mode, pressing this button toggles
between CAM selection and PGM selection modes.
In Playlist Edit mode, pressing this button inserts
the clip loaded on the PRV channel into current
playlist.
LEVER Changes the lever range to secondary mode (see
setup menu for range selection)
6. Operational
Block 2
PLAY Initiates playback
NETWORK Enters the XNet menu. (connect to other servers on
the network)
LAST CUE Re-cues machine to previous cue point
GOTO TC Allows timecode entry, with «F» keys
FAST JOG Used with jog dial for rapid, manual re-cue. This
mode is automatically reset after PLAY/LIVE
commands.
MARK Used to enter re-usable cue point (256 cycling
cues).
RECORD Initiates “E2E” mode
RETURN Inside a clip, allows the operator to return to the
