Test Setup - Test Configurator, Timer, and System
114 MAX-800 Series
Interface
Speed, available with 10/100/1000M Electrical interface, allows the
selection of the interface rate: 10M, 100M, 1GE, or Auto
1
. The
negotiated speed will be displayed next to the Speed field selection.
Duplex choices for 10M and 100M electrical interfaces are
Full Duplex (default), Half Duplex, and Auto
1
. For other rates the
Duplex is set to Full Duplex. Availability of choices depend on the test
applications. Half Duplex is not available with an active copper SFP.
The negotiated duplex will be displayed next to the Duplex field
selection.
Flow Control choices are Enable TX, Enable RX, Enable RX and TX,
None (default), and Auto
1
. When the Flow Control is set to None,
pause frames received are ignored. Availability of choices depend on
test applications.
Cable Mode is available with 10/100/1000M Electrical interface.
Availability of choices depend on the test application.
Manual mode is selected when the Auto-Negotiation check box is
cleared and allows selecting the type of cable: MDI (default) for
straight through cable or MDIX for crossover cable.
Automatic mode is selected when the Auto-Negotiation check box is
selected and allows the unit to automatically detect the MDI or MDIX
cable type.
Local Clock is only available with 1GE electrical interface and allows
setting the source of the clock: Master (default), Slave
2
, or Auto
1
.
1.
Auto
is only available when the
Auto-Negotiation
check box is selected.
2.
Slave
is the only available choice for Wander test application.
