Test Setup - Test Configurator, Timer, and System
130 MAX-800 Series
MAC/IP/UDP
The following configuration parameters are available for both IPv4 and
IPv6 unless otherwise specified.
Quick Ping button automatically starts the quick Ping utility for the
stream destination IP address and provides either a successful or failed
result. The quick Ping uses 3 attempts, a Delay of 1 second, a Timeout
of 2 seconds, and a Data Size of 32 Bytes. Refer to Ping & Trace Route
on page 357 for more options.
Resolve MAC Address check box, when selected (default), sends a
request to the network to retrieve the MAC address corresponding to
the selected destination IP address. This setting is coupled with the
Resolve MAC Address check box from MAC on page 123. The Resolve
MAC address status is displayed. Possible status are:
Source IP Multiplicator check box, when selected (cleared by
default), allows changing the 7 LSB (Least Significant bit) of the source
IP address as specified in the range: 1-128 (default) or 0-127. .
Subnet Mask (IPv4) allows entering the Subnet Mask for the stream.
The default setting is 255.255.0.0. Not available when the Automatic IP
(DHCP) check box is selected.
Default Gateway (IPv4) check box, when selected (cleared by
default), allows entering a default Gateway IP address. When the
Default Gateway check box is selected, its default address is 0.0.0.0.
The Default Gateway address is not configurable when the Automatic
IP (DHCP) check box is selected.
Status Description
-- The Resolve MAC address is not enabled.
Resolving The MAC address is being resolved.
Resolved The MAC address is resolved.
Failed The MAC address cannot be resolved.
