Test Setup - Test Configurator, Timer, and System
MaxTester 149
RFC 2544 - Subtests
Thresholds Button
Note: For Dual Test Set, thresholds are configurable for Local to Remote and
Remote to Local directions at the exception of Round-Trip Latency
Threshold for which the value is unique. For Dual Port topology, thresholds
are configurable for both port directions.
 Throughput Threshold sets the threshold
1
value used to declare a
pass/fail verdict for all frame sizes when applicable. The range is as
follows:
 Back-to-Back Threshold sets the threshold
1
value in percentage of
frames per burst to declare a pass/fail verdict for all frames sizes when
applicable.
 Frame Loss Threshold (%) sets the threshold
2
value of frame loss for
all frame sizes when applicable.
1. The verdict is PASS when the received/measured value is greater or equal to the threshold value.
Interface
Speed
Max. Rate
% Mbit/s Gbit/s
10 Mbit/s 0.0 to 100.0
a
a. Defalut value.
0.0 - 10.0
a
Not Applicable
100 Mbit/s 0.0 to 100.0
a
0.0 - 100.0
a
Not Applicable
1000 Mbit/s 0.0 to 100.0
a
0.0 - 1000.0
a
0.0 - 1.0
a
10G LAN 0.0 to 100.0
a
0.0 - 10000.0
a
0.0 - 10.0
a
10G WAN
b
b. The maximum value for 10G WAN may be lower depending on the frame size. The
maximum value will be adjusted for each frame size.
0.0 to 92.857
a
0.0 - 9285.7
a
0.0 - 9.2857
a
100G 0.0 to 100.0
a
0.0 - 100000.0
a
0.0 - 100.0
a
2. The verdict is PASS when the received/measured value is lower or equal to the threshold value.
