DTP CrossPoint 84 Series Matrix Switchers • Introduction 3
The DTP CrossPoint can be operated by any of the following connected to either serial port
or a LAN port:
• A control system
• A PC and any of the following:
• The Extron SIS
• The Extron Windows-based DSP Configurator program
• The Extron Windows-based Product Configuration Software (PCS)
• An Extron MKP 2000 remote control panel
• An Extron MKP 3000 remote control panel
• (RS-232 only) An Extron MCP 1000 remote control panel and/or MKP 1000 remote
keypad
Setup of the IPCP control processor, built into IPCP models, requires the Extron Global
Configurator, which is available for download from the Extron Web site. The processor offers
RS-232 and IR-based control, relays, and digital I/O controls that can control and monitor a
variety of external devices, such as projectors and lights.
The switcher is housed in a rack-mountable, 2U high metal enclosure with mounting flanges
for a standard 19-inch rack. The appropriate rack mounting kit is included with the switcher.
The switcher has an internal 100 VAC to 240 VAC, 50-60 Hz, 180 watts power supply that
provides worldwide power compatibility.
DTP Input and Output Signals
The DTP inputs and outputs are proprietary signals that are created within any of the Extron
DTP Extender systems and transmitted over a single shielded twisted pair (STP) cable.
The DTP CrossPoint accepts DTP inputs from transmitting devices such as the
DTP T USW 333. Depending on the connected transmitting model, it generates the DTP
signal from a variety of video and audio inputs, including HDMI, DVI, analog VGA, and
embedded and analog audio. The DTP signal can also include bidirectional RS-232 and IR
control signals from the connected transmitting and receiving devices or inserted locally, on
the DTP CrossPoint switcher.
Depending on the transmitting or receiving device, the DTP inputs and outputs can travel up
to 330 feet (100 meters) or 230 feet (70 meters) without a loss of signal integrity.
