DTP CrossPoint 84 Series Matrix Switchers • Operation 26
F
Esc (
>
) button (see figure17 on page22) — The Esc (
>
) button has one primary
function () and five secondary functions (•):
Cancels operations or selections in progress and resets the front panel button
indicators and blinks once to indicate that the escape function has been activated.
• With the View button, indicates Input Audio Configuration mode.
• With the Enter, Preset, and View buttons, selects Serial Port Configuration mode.
• Selects 115200 baud for the rear panel Remote port in Serial Port Configuration
mode and indicates the selection.
• With the Preset Preset and View button, selects between front panel locks
(Lock mode 2 and Lock mode 0).
• With the View button, selects between front panel locks (Lock mode 2 and
Lock mode 1).
I/O Buttons
NOTE: See Front Panel Operations starting on page28 for detailed descriptions of
the following operations.
Primary functions
Action Select video Select audio
Indication Green: selected Red: selected
VIDEO AUDIO
Secondary functions
Control insert
configuration
Indication Blink: Control Insert Configuration Mode.
Resets Action: Perform a system reset.
G
Video button — The Video button has one primary function () and two secondary
functions (•):
Selects and deselects video for a configuration that is being created or viewed and
lights green to indicate that video is available for configuring or for viewing.
•
W
ith the Audio button, indicates Control Insert Configuration mode.
•
W
ith the Audio button, commands the front panel system reset.
H
Audio button — The Audio button has one primary function () and two secondary
functions (•):
Selects and deselects audio for a configuration that is being created or viewed and
lights to indicate that audio is available for configuration or viewing.
• With the Video button, indicates Control Insert Configuration mode.
• With the Video button, commands the front panel system reset.
Esc button
Video button
Audio button
