DTP CrossPoint 84 Series Matrix Switchers • Programming Guide 54
Switcher-initiated Messages
When a local event such as a front panel operation occurs, the switcher responds
by sending a message to the host. The switcher-initiated messages are listed below
(underlined).
The switcher does not expect a response from the host, but, for example, the host program
might request a new status.
(c) Copyright 20yy, Extron Electronics DTPCP84, Vx.xx, 60-nnnn-nn
]
{day, date, time}
]
The switcher initiates the Copyright message on the Remote RS-232 port when it is first
powered up and on a newly connected Internet protocol (IP) port. Vx.xx is the firmware
version number and 60-nnnn-nn is the switcher part number.
Password:
]
The switcher initiates the Password message immediately after the copyright message when
the controlling system is connected using TCP/IP or Telnet and the switcher is password
protected. This message means that the switcher requires an administrator or user level
password before it will perform the commands entered via this link. The switcher repeats
the password message response for every entry other than a valid password until a valid
password is entered.
NOTE: The factory configured passwords for all accounts on this device have been
set to the device serial number. Passwords are case sensitive. If the device is
reset, the password will be the original password configuration.
]
Login Administrator
]
]
Login User
]
The switcher initiates the Login message when a correct administrator or user password
has been entered. If the user and administrator passwords are the same, the switcher
defaults to administrator privileges.
Qik
]
The switcher initiates the Qik message when a front panel tie creation has occurred.
Rprnn
]
The switcher initiates the Rpr message when a memory preset has been recalled from the
front panel. “nn” is the preset number.
Amtnn*x
]
The switcher initiates the Amt message when an output audio mute is toggled on or off from
the front panel. nn is the output number and x is the mute status: 1 = on, 0 = off.
GrpmDn*y
]
The switcher initiates the Grpm message when a front panel Volume knob is adjusted. “n” is
the control: 1 (Mic Volume) or 2 (Volume).”y” is the variable.
Exen
]
The switcher initiates the Exe message when the front panel security lockout (executive
mode) is toggled on or off from the front panel. “n” is the executive mode: 0, 1, or 2.
