SMP 111 • Front Panel Operation 24
EDID on HDMI connector
EDID emulation is available on the HDMI input. By default, custom EDID is set to
720p@60Hz, 2-channel audio. The selected input is displayed in the first line.
EDID Resolution Refresh Rate Rate Type Video Forma Audio
1 800x600 60 Hz PC DVI N/A
2 1024x768 60 Hz PC DVI N/A
3 1280x720 60 Hz PC DVI N/A
4 1280x768 60 Hz PC DVI N/A
5 1280x800 60 Hz PC DVI N/A
6 1280x1024 60 Hz PC DVI N/A
7 1360x768 60 Hz PC DVI N/A
8 1366x768 60 Hz PC DVI N/A
9 1400x1050 60 Hz PC DVI N/A
10 1440x900 60 Hz PC DVI N/A
11 1600x900 60 Hz PC DVI N/A
12 1600x1200 60 Hz PC DVI N/A
13 1680x1050 60 Hz PC DVI N/A
14 1920x1080 60 Hz PC DVI N/A
15 1920x1200 60 Hz PC DVI N/A
16 800x600 60 Hz PC HDMI 2-Ch
17 1024x768 60 Hz PC HDMI 2-Ch
18 1280x768 60 Hz PC HDMI 2-Ch
19 1280x800 60 Hz PC HDMI 2-Ch
20 1280x1024 60 Hz PC HDMI 2-Ch
21 1360x768 60 Hz PC HDMI 2-Ch
22 1366x768 60 Hz PC HDMI 2-Ch
23 1400x1050 60 Hz PC HDMI 2-Ch
24 1440x900 60 Hz PC HDMI 2-Ch
25 1600x900 60 Hz PC HDMI 2-Ch
26 1600x1200 60 Hz PC HDMI 2-Ch
27 1680x1050 60 Hz PC HDMI 2-Ch
28 1920x1200 60 Hz PC HDMI 2-Ch
29 480p 60 Hz HDTV HDMI 2-Ch
30 576p 50 Hz HDTV HDMI 2-Ch
31 720p 50 Hz HDTV HDMI 2-Ch
32 720p 60 Hz HDTV HDMI 2-Ch
33 1080i 50 Hz HDTV HDMI 2-Ch
34 1080i 60 Hz HDTV HDMI 2-Ch
35 1080p 25 Hz HDTV HDMI 2-Ch
36 1080p 50 Hz HDTV HDMI 2-Ch
37 1080p 24 Hz HDTV HDMI 2-Ch
38 1080p 60 Hz HDTV HDMI 2-Ch
39 User Loaded Slot 1
40
User Loaded Slot 2
41 User Loaded Slot 3
