SMP111 • Web-Based User Interface 60
The File Management page opens showing the File Directory (see figure 49,
1
)
and the File Upload Utility (
2
) panels:
1 2
3
Figure 49. File Management Page
The storage information table (see figure 49,
3
) in the lower right of the File
Management page (also displayed in the middle of the Device Status page) displays the
names of the available connected storage devices, their locations (internal, USB front panel
port, USB rear panel port, RCP USB), total capacity, and amount of used and available
storage space. It also provides an estimate of remaining recording time for each drive.
Figure 50. Storage Information Table
This list can be sorted. Click on any of the table headings or click the arrow that appears
when you hover the pointer over a table heading and select a sort order from the drop-down
list.
See the SMP111HelpFile for information on using the file manager with the Web-based
UI.
NOTE: Recordings stored on the internal drive can be automatically uploaded to a
network server (configured in Recorded Events > Publish Settings). If internal
storage space is nearly full and the SMP is set up to automatically upload recordings
to a server, the SMP uses a disc cleanup feature to make room for new recordings. As
needed, the unit automatically deletes old recordings that have already been uploaded
to a server, starting with the oldest recordings, until there is enough free space on the
SD card.
figure 49
figure 50
