SMP 111 • Remote Communication and Control 82
Command and Response Tables (continued)
NOTES:
X1)
= Input name Name (up to 16 characters) Default is "Input X" where "X" is the input number
X1*
= Aspect ratio 1 = Fill (the input automatically fills the entire output raster; Default)
2 = Follow (the input is displayed in its native aspect ratio)
3 = Fit (the input is zoomed in to fill the entire output raster while maintaining its
aspect ratio)
X2!
= Record status 0 = stop, 1 = recording, 2 = pause, 1 = finalizing
X4#
= Recording destination 0 = Auto, 1 = Internal, 2 = Front USB, 3 = Rear USB, 4 = RCP USB, 11 = Internal and Auto,
12 = Internal and Front USB, 13 = Internal and Rear USB, 14 = Internal and RCP USB
Command
Function
SIS Command
(Host to Device)
Response
(Device to Host)
Additional Description
Input Name
Set input name E X1)
NI
}
Nmi
X1)]
Set the name
X1)
.
View input name E
NI
} X1)]
NOTE: To clear an input name, a single space character should be entered for
X1)
. The name resets back to the default setting.
Input video aspect ratio
Set to fill E
1ASPR
}
Aspr1
]
Set to follow E
2ASPR
}
Aspr2
]
Set to fit (zoom) E
3ASPR
}
Aspr3
]
View aspect ratio
setting
E
ASPR
} X1*]
Execute Auto-Image
Execute
A
] Follow current aspect setting.
Execute and fill
1*A
] Fill the entire output.
Execute and follow
2*A
] Follow the input aspect ratio.
Recording Controls
Stop recording E
Y0 RCDR
}
RcdrY0
]
Start recording E
Y1 RCDR
}
RcdrY1
]
Pause recording E
Y2 RCDR
}
RcdrY2
]
View record status
E
Y RCDR
} X2!]
Chapter Marker
Add chapter marker E
B RCDR
}
RcdrB
] Manually insert chapter marker.
Recording Time
View recording
duration/elapsed time
of recording
35I
HH:MM:SS
]
Inf35*HH:MM:SS
]
Displays 00:00:00 when not
recording.
Verbose mode 2/3.
View record time
remaining (Internal +
Secondary recording)
36I Internal•HH:MM:SS*
usbstorage•HH:MM:SS
]
Inf36*Internal•HH:MM:SS*
usbstorage•HH:MM:SS
]
Verbose mode 2/3.
View record time
remaining (Single
recording)
36I SelectedStorage
HH:MM:SS
]
Inf36*SelectedStorage•
HH:MM:SS
]
Verbose mode 2/3.
Record Destination
Set Record
Destination
E
D
X4#
RCDR
}
RcdrD
X4# ]
Select record destination for
recording(s).
View record
destination
E
D RCDR
} X4#]
View recording destination for
next recording.
