SMP 111 • Remote Communication and Control 89
Command and Response Tables (continued)
Table 1. EDID Values
X3$
Resolution Refresh Rate Type Video Format Audio
01 800 x 600 60 Hz PC DVI N/A
02 1024 x 768 60 Hz PC DVI N/A
03 1280 x 720 60 Hz PC DVI N/A
04 1280 x 768 60 Hz PC DVI N/A
05 1280 x 800 60 Hz PC DVI N/A
06 1280 x 1024 60 Hz PC DVI N/A
07 1360 x 768 60 Hz PC DVI N/A
08 1366 x 768 60 Hz PC DVI N/A
09 1400 x 1050 60 Hz PC DVI N/A
10 1440 x 900 60 Hz PC DVI N/A
11 1600 x 900 60 Hz PC DVI N/A
12 1600 x 1200 60 Hz PC DVI N/A
13 1680 x 1050 60 Hz PC DVI N/A
14 1920 x 1080 60 Hz PC DVI N/A
15 1920 x 1200 60 Hz PC DVI N/A
16 800 x 600 60 Hz PC HDMI 2‑Ch
17 1024 x 768 60 Hz PC HDMI 2‑Ch
18 1280 x 768 60 Hz PC HDMI 2‑Ch
19 1280 x 800 60 Hz PC HDMI 2‑Ch
20 1280 x 1024 60 Hz PC HDMI 2‑Ch
21 1360 x 768 60 Hz PC HDMI 2‑Ch
22 1366 x 768 60 Hz PC HDMI 2‑Ch
23 1400 x 1050 60 Hz PC HDMI 2‑Ch
24 1440 x 900 60 Hz PC HDMI 2‑Ch
25 1600 x 900 60 Hz PC HDMI 2‑Ch
26 1600 x 1200 60 Hz PC HDMI 2‑Ch
27 1680 x 1050 60 Hz PC HDMI 2‑Ch
28 1920 x 1200 60 Hz PC HDMI 2‑Ch
29 480p 60 Hz HDTV HDMI 2‑Ch
30 576p 50 Hz HDTV HDMI 2‑Ch
31 720p 50 Hz HDTV HDMI 2‑Ch
32*
720p 60 Hz HDTV HDMI 2‑Ch
33 1080i 50 Hz HDTV HDMI 2‑Ch
34 1080i 60 Hz HDTV HDMI 2‑Ch
35 1080p 25 Hz HDTV HDMI 2‑Ch
36 1080p 50 Hz HDTV HDMI 2‑Ch
37 1080p 24 Hz HDTV HDMI 2‑Ch
38 1080p 60 Hz HDTV HDMI 2‑Ch
39 User Loaded Slot 1
40 User Loaded Slot 2
41 User Loaded Slot 3
* Default
