SMP 111 • Remote Communication and Control 88
NOTES:
X@
= Audio channels 40000 = Analog audio left, 40001 = Analog audio right,
40002 = HDMI audio left, 40003 = HDMI audio right
X(
= HDCP status 0 = no sink/on/source detected, 1 = sink/source detected with HDCP
2 = sink/source detected but no HDCP
X2@
= Audio delay 000 to 999 ms (Default 0 ms, 3‑digit response)
X2#
= Audio level -1500 to 0 (in 0.1 dBfs step)
X2*
= Audio input gain Audio level in 0.1 dB steps (‑180 to 240 = ‑18.0 to +24.0 dB)
X3#
= Mute status 0 = unmuted (Default).
1 = muted
X3$
= EDID number See Table 1. EDID Values on the next page
X3&
= Audio output 1 = HDMI only, 2 = Analog only, 3 = HDMI and Analog
X3(
= EDID user slot 1 to 3
Command and Response Tables (continued)
Command
Function
SIS Command
(Host to Device)
Response
(Device to Host)
Additional Description
HDCP Status
Query HDMI input E
IHDCP
} X(]
EDID Minder
Assign EDID to
specific input
E
A
X3$
EDID
}
EdidA
X3$ ] X3$
= See Table 1. EDID
Values on the next page.
View EDID
assignment
E
AEDID
} X3$ ] View EDID resolution and
refresh.
Import EDID to user
location
E
I
X3(
,[lename.bin]
EDID
}
EdidI
] Import a 128 or 256‑Byte binary
EDID file to the user slot [1 to 3].
Export EDID in binary
format
E
E
X3$
,[lename.bin]
EDID
}
EdidE
] Export a 128 or 256‑Byte binary
EDID file from EDID location
X3$
. [filename] can optionally
carry a full path name. The EDID
file is a .bin file.
Recall Audio Output Preset (Mixed, Analog only, or HDMI only)
Recall Preset X3&
. Rpr
X3&]
Recall audio output preset
X3&
.
Audio Gain and Attenuation
Set gain and
attenuation
E
G
X@
*
X2*
AU
}
DsG
X@
*
X2*]
Set audio gain and attenuation
of audio channel
X@
to
X2*
.
View gain and
attenuation
E
G
X@
AU
} X2*] View audio level of audio
channel
X@
.
Audio Delay
NOTE: Set the audio delay to zero to disable it.
Set audio delay
E X2@
ADLY
}
Adly
X2@]
Set audio delay to
X2@
.
View delay E
ADLY
} X2@ ] View audio delay.
Audio Mute
Mute audio channel
E
M
X@
*1AU
}
DsM
X@
*1
]
Mute audio channel.
Unmute audio
channel
E
M
X@
*0AU
}
DsM
X@
*0
]
Unmute audio channel.
View mute status E
M
X@
AU
} X3#] View audio mute status.
Audio Output Level
View level
34I
X2#
*
X2#]
Inf34*
X2#
*
X2#]
Left*right channel of the output
audio.
Verbose mode 2/3.
