RESTRICTED USE ONLY FARGO Electronics, Inc.
DTC500 Series Card Printer/Encoders Troubleshooting Guide (Rev. 3.0)
154
Using the Overlay / Print Area dropdown menu
Step Procedure
1
Select the Full Card option for the Printer to overlay and/or print the entire card.
OR
Select the Defined Area(s) option for the Printer to overlay and/or print only in
the selected and defined area or areas.
OR
Select the Undefined Area(s) option for the Printer to overlay and/or print only in
the space outside the selected and defined area.
OR
Select the Omit Smart Chip Area option for the Printer to overlay and/or print
only in the space outside the standard location of a smart chip.
OR
Select the Omit Mag Stripe Area option for the Printer to overlay and/or print
only in the space outside the standard location of an ISO Magnetic Stripe.
OR
Select the Omit Signature Area option for the Printer to overlay and/or print only
in the space outside the standard location of a signature panel.
(Note: In the card grid, black indicates the area in which the overlay and/or
printing will be applied.)
Continued on the next page
