Replacing the Main Board (D850427)
For Use with DTC520/DTC525 without Embedded Fonts and Barcodes
Tools Required: Phillips-head Screwdriver, Torx T10 Screwdriver, Needle-nose Pliers, Wire
Cutter
Step Procedure
1
Caution: Turn OFF the Printer and unplug the power cord from the
Printer.
2 Lift up on the bottom edge of the Top Lid (D850289); tilt it back into the fully
open position.
3 Use the Phillips-head Screwdriver to remove the two screws (130939) located
near the hinges. Open the Card Hopper Door before raising the cover.
4 Pull back the plastic tabs at each of the four corners of the cover.
5 Carefully lift the cover off of the Printer. Remove the LCD interface cable
(D850481) at the main circuit board, and disconnect the grounding cable at the
power supply casing.
6 Completely remove the Card Output Hopper (D850290) from the Printer by
pulling back the release tab at the bottom of the Printer. Remove the two circuit
board mounting screws located in the hopper opening.
7 Remove the circuit board mounting screw located below the Printhead lifter arm
pivot.
8 From the back of the Printer, use the Torx T10 Screwdriver to remove the top
three circuit board mounting screws located at the left, middle and right sections.
9 Along the left edge of the circuit board, remove the two (2) mounting screws at
the middle and lower section.
Continued on the next page
