RESTRICTED USE ONLY FARGO Electronics, Inc.
DTC500 Series Card Printer/Encoders Troubleshooting Guide (Rev. 3.0)
65
Replacing the Flipper Home Sensor (140407)
Tools Required: Phillips-head Screwdriver, Torx T10 Screwdriver
Step Procedure
1
Caution: Turn OFF the Printer and unplug the power cord from the
Printer.
2 Lift up on the bottom edge of the Top Lid (D850289); tilt it back into the fully
open position.
3 Use the Phillips-head Screwdriver to remove the two screws (130939) located
near the hinges.
4 Release the plastic tabs in the four corners of the cover.
5 Lift the cover off of the Printer.
6 Use the Torx T10 Screwdriver to remove the two screws that secure the Sensor
Board Assembly.
7 Disconnect the Sensor Board Assembly Cable.
To Next Page
