DTC500 Series Card Printer/Encoders Troubleshooting Guide (Rev. 3.0)
187
LCD On-Line Menu Navigation
The purpose of this section to provide the User with specific procedures for LCD On-Line
Menu Navigation, Test Image Printing, and Printer Setup for the DTC500 card Printer.
Entering the LCD Menu and selecting an Option
The MENU option is above the center softkey button, as shown below. This allows access to
several test, setup, and reporting functions. The Selecting from the Menu Option Tree
Structure on page 188, shows the available menu options. A description of each option and
its function is included on the pages following the on-line menu.
Step Procedure
1
Press the MENU button to bring up the Select Function screen appears, as
shown here.
Use the scroll buttons to move up or down through the menu options, as shown
below. (Note: The brackets appear on either side of the active Menu option.)
Press the button below Select to choose an option. Choose from these five
categories: Print Test Image, Setup Printer, Show error count, Show card
count, and System Upgrade.
MENU
Ready
DTC5XX
MENU
H-1 H-2
SELECT FUNCTION
SELECT
HELP
EXIT
[Print Test Image]
Setup Printer
