RESTRICTED USE ONLY FARGO Electronics, Inc.
DTC500 Series Card Printer/Encoders Troubleshooting Guide (Rev. 3.0)
33
Reviewing the DTC500 Board Cable Connections Reference
Purpose Location
Power Supply J1
No Cable Assembly: Parallel Port Connection J11
No Cable Assembly: DRAM Connector J12
Fan J13
Fan J14
Card Detection Sensor and Flipper Table Card Sensor J15
Ribbon Sensor Array J16
Unpopulated J17
LCD J18
Background Mode Debugger Connection, Program Loading J19
Smart/Proximity Card Interface J21
Ribbon Supply Motor, Ribbon Take-up Motor and Headlift Motor J23
Continued on the next page
