Using the Overlay / Print Area (continued)
Step Procedure
4 Follow this procedure once the area is sized properly.
a. Measure the location this desired area to be positioned on the card.
b. Measure from the lower left corner of the card (up and over) to the lower left
corner (for the defined area to begin).
c. Enter these values into the X and Y boxes. (Note: The card grid lines are
spaced at .2 inch / 5mm intervals.)
Continued on the next page
X=1.3“
ID# 1234478
