RESTRICTED USE ONLY Fargo Electronics, Inc.
DTC500 Series Card Printer/Encoders User Guide (Rev. 5.0)
105
Resolving the Headlift Error Message
Symptom: The Printer was unable to raise or lower the Printhead.
Step Procedure
1
Press the Resume button to retry.
2 If the Headlift does not rotate, check the Headlift Motor (A000124) to ensure
that it is running.
3 If the Headlift Motor is not running, replace the Headlift Motor. See the
Replacing the Headlift Motor (A000124) procedure in Section 5, page Error!
Bookmark not defined..
4 If the head cycles but does not stop at the position every time, check the
Headlift Sensor as described in Sensor Testing in Section 7, page 248.
5 If the Headlift Sensor is failing, replace it. See the Replacing the Headlift
Sensor (A000126) in Section 5, page Error! Bookmark not defined..
