DTC500 Series Card Printer/Encoders User Guide (Rev. 5.0)
52
Reviewing the Lamination Top Cover and Station
Component Description Cross Reference
Lamination
Top Cover
Opens to allow access to the Lamination
Station, overlaminate and card path.
See the Loading the
Overlaminate in Section 3,
page 134.
Lamination
Station
Transfers overlaminates onto cards via its
heated lamination Roller. The Lamination
Station must be closed in order for the
Printer to begin laminating.
See the Loading the
Overlaminate in Section 3,
page 134.
Top Cover
Securing
Latches
Lamination
LED Light
Cancel
Button
Resume
(pause) Button
Rejection
Card Hopper
Card Output
Hopper
