RESTRICTED USE ONLY Fargo Electronics, Inc.
DTC500 Series Card Printer/Encoders User Guide (Rev. 5.0)
53
Reviewing the Securing Latches and Lamination LED light
Component Description Cross Reference
Securing
Latches
Locks the Lamination Station securely in
place when closed.
See the Using the
Lamination tab (only with the
Card Lamination Module) in
Section 5, page 228.
Lamination
LED light
The Lamination LED light works in
conjunction with the Printer's LCD display to
help communicate the Printer's current
status. The following explains how to
interpret the LED light.
Off: Indicates the Printer and lamination
module power is OFF.
Solid Green light: Indicates the Card
Lamination Module is ready for
operation.
Slow Flashing Green light: Indicates
the lamination module's (pause) button
was pushed and that the lamination
module is paused. This also occurs
when the Lamination Station is open.
Fast Flashing Green light: Indicates
the lamination module is in need of
attention due to an error or an error
condition. Refer to the Printer's LCD
display for information.
See the Troubleshooting the
LCD Messages in Section 2,
page 65.
