RESTRICTED USE ONLY Fargo Electronics, Inc.
DTC500 Series Card Printer/Encoders User Guide (Rev. 5.0)
143
Adjusting the Internal Card Guide
The Internal Card Guide is what holds the card in position as it feeds through the Card
Lamination Module.
Step Procedure
1 Feed a blank card into the module by inserting it through the Output Hopper
and reverse feeding it by pressing the lamination module's Resume button.
Manually position the card so its edge is flush with the Card Guide Rail.
Continued on the next page
Screws
Internal Card Guide
CR90
CR80
To Next Page
