RESTRICTED USE ONLY Fargo Electronics, Inc.
DTC500 Series Card Printer/Encoders User Guide (Rev. 5.0)
176
Measuring the Total Card area
Step Procedure
1
Determine the area of the card to define. (Note: This area is indicated by the
dashed outline, as shown below. The easiest way to determine the size of this
area is to actually print a card and look at it in the same orientation as when it
exits the Printer.)
2 Measure the total area and enter those dimensions into the Dimension boxes.
(Note: The minimum size for an area is .2" x .2" (5mm x 5mm).) See the next
page.
