Reviewing the Sensor Location and Voltages
Sensor Location Pin Low Range VDC High Range VDC
Card Sensor
(near Cleaning
Cart)
J15 4 Unblocked .17 - .9 Blocked 3.0 – 3.3
Cover Open
Sensor (plastic
top)
J4 16 Unblocked .17 - .9 Blocked 3.0 – 3.3
Encoding TOF
Platen Home
J29 4 Unblocked .17 - .9 Blocked 3.0 – 3.3
Flipper Table
Card Sensor
J15 8 Unblocked .17 - .9 Blocked 3.0 – 3.3
Flipper Table
Sensor
J7 4
Covered  .9
Uncovered 3.0 - 3.3
Hopper Lift
Sensor
J4 12 Unblocked .17 - .9 Blocked 3.0 – 3.3
Dual Hopper
Position
J32 4 Unblocked .17 - .9 Blocked 3.0 – 3.3
Printhead lift
Sensor
J6 8 Unblocked .17 - .9 Blocked 3.0 – 3.3
Magnetic Card
Sensor
J7 8
Covered  .9
Uncovered 3.0 - 3.3
Bypass
Feed/Hopper
Card Sensor
J4 4
Covered  .9
Uncovered 3.0 - 3.3
Hopper Door
Sensor (not used)
J4 8 Unblocked .17 - .9 Blocked 3.0 – 3.3
Continued on the next page
