RESTRICTED USE ONLY Fargo Electronics, Inc.
DTC500 Series Card Printer/Encoders User Guide (Rev. 5.0)
168
Using the Image Color tab (continued)
Step Procedure
2
Select the None or Monitor option (see the Device options tab, shown below) to
only display the Dye-Sub Intensity and Resin Heat sliders.
3 Control the overall darkness and lightness of the dye-sub printed image by
adjusting the Dye-Sub Intensity slide by clicking and dragging the slide's box.
Move the slide to the left to cause less heat to be used in the printing process,
thus generating a lighter print.
OR
Move the slide to the right to cause more heat to be used, thus generating a
darker print.
(Note: This slide only affects those images printed with Dye-Sublimation Ribbon
panels (YMC).)
Continued on the next page
