Chapter 6 Fastening Operation
PAGE 6-44
D-No.010 controller Maximum Current Cannot be changed
This indicates the maximum current value of the controller.
D-No. 011 IP Address (upper 6 digits) D-No. 012 IP Address (lower 6 digits)
Setting range: 0 to 255
The IP address for the controller Ethernet port is set here. In a MULTI system, the Ethernet port for
the MASTER spindle is only used. (Slave spindles will still display IP addresses, but are not used)
D-No. 013 Subnet Mask (upper 6 digits) D-No. 014 Subnet Mask (lower 6 digits)
Setting range: 0 ～ 255
The subnet mask is set here.
D-No. 015 Default Gateway (upper 6 digits) Setting range: 0 ～ 255
D-No. 016 Default Gateway (lower 6 digits) Setting range: 0 ～ 255
The default gateway is set here.
･After changing the settings of D-Nos. 011 ～ 016, power must be cycled on the
controller for the settings to activate.
･Changes can only be made when the controller is in Program mode (“ProG”indicated in
the upper display) The controller must be put back to RUN mode (“ProG” no longer
displayed in upper display) before powering down or the change will not be stored to
memory.
D-No. 017 MAC Address (upper 6 digits) D-No. 018 MAC Address (lower 6 digits)
Cannot be changed
The MAC address is indicated.
D-No. 019 RTC: Year/Month/Day Setting range: 13～99 (year), 1～12 (month), 1～31 (day)
D-No. 020 RTC: Time Setting range: 0 ～ 23 (hours), 0 ～ 59 (minutes), 0 ～ 59 (seconds)
The date and time of the real time clock (RTC) The range for the year is 2013 ～ 2099.
* This is not indicated at a SLAVE Axis of the multi system.
D-No. 021 Erase Fastening Record/Format CF Card
Erasing of the fastening results history can be executed. Please refer to “Copying of Parameters and
Erasing of the Fastening Result History” in Section 8-6 regarding the method for erasing the fastening
results history.
If installed, formatting of the CF card can be executed. Please refer to “Formatting the Memory Card”
regarding the method for formatting the CF card.
D-No. 022 Parameter Copy
Copying of parameters is performed. Please refer to “Copying of Parameters and Erasure of the
Fastening Result Record” regarding the method for copying parameters.
D-No.023,024,025,028,029 For Adjustment by the Manufacturer
Not used.
