Chapter 9 Fieldbus I/O Interfaces
PAGE 9-16
When the HFC3000 Fieldbus unit is added to the I/O configuration, the data table will be added to the
controller tags automatically.
HFC3000_2:I (shown as AFC1500 in above screenshot)
Input signals from AFC3000 controller. (FEC to PLC)
HFC1500_2:O (shown as AFC1500 in above screenshot)
Output signals to AFC3000 controller. (PLC to FEC)
HFC1500_2:C (shown as AFC1500 in above screenshot)
Message communication data from the HFC3000 controller. (HFC Controller to PLC for fastening result data.)
An additional program/command needs to be added for sending/retrieving the data.
