NG: FASTENING REJECT SIGNAL PIN No.: TB2-1 OUT-1
Output when the fastening result falls outside programmed limits.
OK: FASTENING ACCEPT SIGNAL PIN No.: TB2-2 OUT-2
Output when the fastening result is acceptable within the programmed limits.
ABNORMAL: SYSTEM ERROR / ABNORMAL PIN No.: TB2-3 OUT-3
Output when a system fault / error is detected during a system check or during the fastening process.
When an error occurs, fastening is stopped immediately and the fastening results data is stored.
Normal process cannot begin until the problem is corrected and a RESET signal is input.
READY SIGNAL PIN No.: TB2-4 OUT-4
Output when the system is in the READY condition. Indicates system is ready to operate and inputs
are enabled. This signal is inactive (off) in the following conditions:
• During the initialization process when power is turned on (for approx.. 5 sec.)
• STOP condition
• While fastening is in process (when BUSY)
• While Reset signal is on
• Bypass condition
• Abnormal condition
• When a START or REVERSE signal is on
• During a CAL check
• When operation of the system by an external input is impossible
BUSY SIGNAL PIN No.: TB2-5 OUT-5
Output when the controller is in cycle for a fastening process.
FASTENING RESULT DATA AVAILABLE SIGNAL PIN No.: TB3-7 OUT-6
Output “ON” when the fastening results are available to be collected via the HFC software.
This signal turns “OFF” after data collection has completed and can be used to monitor that the
HFC3000 software is monitoring / collecting data (when AFC3000 Software is used)
CF CARD FULL PIN No.: TB3-8 OUT-7
Output when capacity of the (Optional) CF card is less than 1%, or CF memory card is not inserted
BYPASS SIGNAL PIN No.: TB2-6 OUT-12
Output when in the BYPASS / PROGRAM mode.
