6 Positioning mode
Festo – GDCP-CMMS/D-FW-EN – 1404NH – Engli sh 121
Activating the positioning record via digital inputs (record selection bit 0…5)
The positioning record ( 1…63) for the individual record is selected via the record selection bit 0…5.
Positioning
record
Record selection
Bit 5 (2
5
)
(DIN11)
[X1.16]
[X1.1.16]
[X1.2.16]
Bit 4 (2
4
)
(DIN10)
[X1.3]
[X1.1.3]
[X1.2.3]
Bit 3 (2
3
)
(DIN3)
[X1.8]
[X1.1.8]
[X1.2.8]
Bit 2 (2
2
)
(DIN2)
[X1.20]
[X1.1.20]
[X1.2.20]
Bit 1 (2
1
)
(DIN1)
[X1.7]
[X1.1.7]
[X1.2.7]
Bit 0 (2
0
)
(DIN0)
[X1.19]
[X1.1.19]
[X1.2.19]
1 0 0 0 0 0 1
2 0 0 0 0 1 0
3 0 0 0 0 1 1
4 0 0 0 1 0 0
…
7 0 0 0 1 1 1
8 0 0 1 0 0 0
…
15 0 0 1 1 1 1
16 0 1 0 0 0 0
…
32 1 0 0 0 0 0
…
63 1 1 1 1 1 1
Tab. 6.3 Overview: Ac tivating the positioning record via digital inputs (record selection bit 0...5)
