5 Commissioning
Festo – GDCP-CMMS/D-FW-EN – 1404NH – Engli sh 99
1. Block the controller enable function (DIN5)[X1.9][ X1.1.9/X1.2.9] = 0 V.
2. Switch on the power supplies (Power ON).
• CMMS-AS /CMMD-A S : Control section 24 V DC/power section: 230 V AC
• CMMS-ST: Control section 24 V DC/power section: 24…48 V DC
If required, the process for downloading t he firmware from the memory card can be
activated via DIL switch [S1.8] , switch position = ON.
The Ready LED on the front of the motor controller should now light up.
The following malfunctions can occur:
– The seven-segment display shows an error message (4-digit characte r sequence
“Exxx”)orawarningmessage(5-digitcharactersequence“–xxx–”) appendix A,
page 216.
– The LED ( Ready/Bus (CMMS -ST/CMM D-AS ) or CAN ( CMMS-AS)) or seven segment
display do not light up.
Perform the following steps:
1. Measure the voltage levels at the input/output of the power supply unit and the
power switch.
2. Switch off the power supplies (Power OFF) .
3. Wait five minutes until the intermediate circuit voltage has discharged.
4. Check the cabling and the connection of the wires at the connection “Powe r supply”.
5. Switch on the power supplies (Power ON).
5.3.5 Downloading device data (FCT) to the motor controller
1. Connect the PC to the motor c ontroller.
Observe the pin allocation of the RS232 interfaces page 235.
2. Star t the Festo Configuration Tool ( FCT).
3. Establish an online connection to the motor controller in the FCT.
Theonlinefirmwaredownloadprocesscanbeexecutedifrequired.
4. Start downloading the device data ( FCT) page 89
