C RS485 serial interface
240 Festo – GDCP-CMMS/D-FW-EN – 1404NH – English
C Serial interface RS485 (control interface)
C.1 Activating the motor controller via the interface RS485
C.1.1 Master data of the interface RS485
Parameter
Significance
Baud rate 9.6
1)
…115 KBit/s
Data bits 8
Parity none
Stop bit 1
1) Factory setting
Tab. C.1 Basic setting
For additional information  “Mounting and installation” description,
GDCP-CMMS-AS-G2-HW-…/GDCP-CMMD-AS -HW-…/GDCP-CMMS-ST-G2-HW-…
C.1.2 Connection [X5]: Pin allocation of the RS4 85 interface
Collision with interface “RS232”.
If the control interface “RS485” is ac tivated, interface “RS232” remains active. If the pins
“2” a nd “3” in the cable are co nta cte d on both plugs, th is can result in the int erfaces
“RS232” and “RS485” simultaneously acc essing the motor controller.
– For communication with the “control interface RS485”, use a cable that corresponds
to the pin allocation “control interface RS 485”.
For additional information  “Mounting and installation” description,
GDCP-CMMS-AS-G2-HW-…/GDCP-CMMD-AS -HW-…/GDCP-CMMS-ST-G2-HW-…
