5 Commissioning
Festo – GDCP-CMMS/D-FW-EN – 1404NH – Engli sh 83
5.1.7 Firmware download activation from the memory card
The process for downloading firmware from the memory card can be configured via DIL switch [S1.8]
 page 87.
Bootloader
DIL switch [S1.8]
ON OFF
Download firmware file (.S) from the memory card after Power ON/FCT:
Reboot controller
active inactive
Tab. 5.3 Firmware download activation from the memory card
5.1.8 Data rate configuration (CAN bus/DeviceNet)
The data rate configuration is evaluated for each power ON procedure or controller reboot (FCT). The
bit/transmission rate can be configured via the DIL switches [S 1.9/S1.10] .
Fieldbus
Bit/transmission rate DIL switch
[S1.10] [S 1.9]
CANopen (CAN bus) /DeviceNet 125 KBit/s (125 kBaud) OFF OFF
250 KBit/s ( 250 kBaud) OFF ON
500 KBit/s ( 500 kBaud) ON OFF
CANopen (CAN bus) 1 MBit/s (1000 kBaud) ON ON
Tab. 5.4 Data rate configuration (CAN bus/DeviceNet)
5.1.9 CAN bus activation
Activation of the C AN bus can be configured via DIL switch [S1.11].
Fieldbus
Port DIL switch [S1.11]
ON OFF
CANOpen CAN bus active
1)
inactive
DriveBus
1) The CAN bus interface is disabled with installation of the interface module “CAMC-PB/PROFIBUS DP” or “CAMC-DN/DeviceNet”.
Tab. 5.5 CAN bus activation
