A Technical appendix
138 Festo – P.BE-MPA-EN – 1309f – English
1
2
3
1 Pressure of the pilot air supply at port
(12/14) [bar]
2 Work range
3 Operating pressure at port (1) [bar]
Fig. A.5 Diagram: Required pilot pressure related to the operating pressure with use of valve sub-ba-
ses with ident. code MU, NU, KU and HU
