A Technical appendix
Festo – P.BE-MPA-E N – 1309f – English 139
The fittings of the pneumatic ports cause a reduction in the nominal flow rate of the
valves.
Standard nominal flow rates MPA1 (width 1 0 mm)
Ident. code
1)
Valve Standard nominal flow rates [I/min], measured with
fitting QS-M7-6-I
1 } 2or1} 4
2)
2 } 3/5 or 4 } 3/5
2)
M, MS, J 5/2-way 360 360
MU 5/2-way 190 (1 } 2)/160 (1 } 4) 190 (2 } 3)/160 ( 4 } 5)
B 5/3-way, pressurized 300 (220)
3)
270
G 5/3-way, c losed 320 320
E 5/3-way, exhausted 240 240 (200)
3)
H 2x 3/2-way 300 300
HS 2x 3/2-way 300 305
K, KS 2x 3/2-way 230 310
N, NS 2x 3/2-way 300 300
KU 2x 3/2-way 160 170
NU 2x 3/2-way 190 160
HU 2x 3/2-way 190 ( 1 } 2)/160 ( 1 } 4) 160 ( 2 } 3)/170 ( 4 } 5)
W, X 1x 3/2-way 255 295
D, DS 2x 2/2-way 230 —
I 2x 2/2-way 260 260
1) Ident. code of the valve sub-base
2) Flow direction 1 } 4or4} 3/5 not with valves having ident. codes I, W and X
3) V alues for the mid-position are specified in brackets
Tab. A.7 Technical data: nominal flow rates MPA1
