A Technical appendix
140 Festo – P.BE-MPA-EN – 1309f – English
Standard nominal flow rates MPA2 (width 20 mm)
Ident. code
1)
Valve Standard nominal flow rates [I/min] measured,
without fitting with fitting QS-Gx-8-I
1 } 2or1
} 4
2)
2 } 3/5 or
4 } 3/5
2)
1 } 2or1
} 4
2)
2 } 3/5 or
4 } 3/5
2)
M, MS, J 5/2-way 700 700 670 670
B 5/3-way, pressurized 520 650 (350)
3)
510 600 (350)
3)
G 5/3-way, c losed 630 630 610 610
E 5/3-way, exhausted 610 440 (350)
3)
590 420 (350)
3)
H, HS, N, NS 2x 3/2-way 560 490 550 480
K, KS 2x 3/2-way 500 560 500 540
W, X 1x 3/2-way 500 590 470 560
D, DS 2x 2/2-way 680 — 650 —
I 2x 2/2-way 680 500 650 500
1) Ident. code of the valve sub-base
2) Flow direction 1 } 4or4} 3/5 not with valves having ident. codes I , W and X
3) V alues for the mid-position are specified in brackets
Tab. A.8 Technical data: nominal flow rates MPA2
Valve switching times MPA1 (width 10 mm)
Ident. code
1)
Valve Valve switching times [ms]
(Measuring method 0 ... 10 % as per F N 942032)
On/changeo ver Off
M 5/2-way, monostable 10 20
MS 5/2-way, monostable 10 27
MU 5/2-way, monostable 10 12
J 5/2-way, bistable 10/15 —
B, G, E 5/3-way valves 10 35
H, K, N 2x 3/2-way 10 20
HS, KS, NS 2x 3/2-way 14 16
KU, HU 2x 3/2-way 8 10
NU 2x 3/2-way 8 8
W, X 1x 3/2-way 10 20
D, I 2x 2/2-way 10 20
DS 2x 2/2-way 14 16
1) Ident. code of the valve sub-base
Tab . A.9 Technical data: valve switching times MPA1
